RS 317-443
Арт.№: 51855
1 от 3
Неналичен
Доставка и плащане
Добави в любими
Твоите любими продукти Сравни
Характеристики RS 317-443
Low pressure air switch 250V AC 0.5A maz
Разпродадено!
Информация
Air Pressure/ Vacuum, Slow Break Versatile Mounting
Rating: Pressure range 1 to 16 in. WG
GF nylon 12 housing, neoprene diaphragm
Repeatability +/-2.5% (Typ)
Two pairs of mounting hole options
| Destruction Pressure | Operating Temperature (°C) | Mechanical Life (Operations) | Height (mm) | Width (mm) | Depth (mm) | Weight (g) |
| 1 bar | -5 to +50 | 1 x 107 | 26 | 42 | 360 | 99 |
Supplied with
1 m of PVC connecting tube
Specifications
- Maximum Pressure Reading: 0.072psi
- Accuracy: ±2.5 %
- Media Measured: Air
- Electrical Connection: 4mm Push Fitting
- Supply Voltage: 250 V ac
- Housing Material: Nylon
- Minimum Operating Temperature: -5°C
- Maximum Operating Temperature: +50°C
