Кръгъл женски съединител 48pin MS3106A36-10P
Кръгъл женски съединител 48pin MS3106A36-10P
- Connector Type: Receptacle, Female Sockets
- Number of Positions: 48
- Shell Size - Insert: 36-10
- Mounting Type: Panel Mount, Flange
- Termination: Solder Cup
- Fastening Type: Threaded
- Orientation: N (Normal)
- Shell Material, Finish Aluminum Alloy, Zinc Plated, Black
- Contact Finish: Silver
- Current Rating: 13A
- Voltage - Rated: 500VAC, 700VDC
Информация
|
Product Name |
N/MS3102A36-10S |
|
Status |
Active |
|
RoHS compliant |
Yes |
|
Connector types |
Receptacle |
|
Number of positions |
48 |
|
Connector styles |
Box mounting |
|
Accessory type |
|
|
Contact shape (Mating part) |
Socket |
|
Wire termination method |
Soldering |
|
Coupling styles |
Threaded |
|
Contact arrangement code |
36-10 |
|
Shell size |
36 |
|
Contact size * No. of contacts |
#16*48 |
|
Contact size |
#16 |
|
Applicable wire size (mm2max.) |
1.25 |
|
Applicable wire (AWG No.) |
#16 AWG |
|
Finish of contact in contact area |
Silver plating |
|
Rated current (A max.) |
13 |
|
Total current rating (A max.) |
124.8 |
|
Dielectric withstanding voltage (VACr.m.s. 1minute) |
2000 |
|
Insulation resistance (megohms min.) |
5000 |
|
Contact resistance (milliohms max.) |
|
|
Waterproof |
None waterproof |
|
Operating temperature range (Deg. C) |
-55 to +125 |
|
Alternative insert position (deg.) |
0 |
|
Outer shell color |
Black system interference color |
