Кръгъл женски съединител 3pin MS3106B22-2S + 3420-12
Арт.№: 49932
1 от 2
Безплатна доставка над
с куриер Спиди
76.69
€
/
149.99
лв.
ППЦ:
€
€
38.3469
€
/
75.00
лв.
Валидност на промоцията
до
В наличност
Доставка и плащане
Резервирай
и вземи от Добави в любими
Твоите любими продукти Сравни
Характеристики Amphenol 3 PIN CONNECTOR MS3106B22-2S + 3420-12 CABLE CLAMP CNC MILITARY
- Series Name: MS Series
- Connector styles: Straight plug
- Number of positions: 3
- Shell size: 22
- Contact shape (Mating part): Socket
- Wire termination method: Soldering
- Applicable wire size (mm2 max.): 3.5
- Applicable wire (AWG No.): #12 AWG
- Finish of contact in contact area: Silver
Информация
Amphenol 3 PIN CONNECTOR MS3106B22-2S + 3420-12 CABLE CLAMP CNC MILITARY
- Series Name: MS Series
- Connector styles: Straight plug
- Number of positions: 3
- Shell size: 22
- Contact shape (Mating part): Socket
- Wire termination method: Soldering
- Contact arrangement code: 18-10
- Contact size * No. of contacts: #12*3
- Applicable wire size (mm2 max.): 3.5
- Applicable wire (AWG No.): #12 AWG
- Finish of contact in contact area: Silver
- Current rating (Amps max.): 23
- Dielectric withstanding voltage (VACr.m.s. 1 minute): 2000
- Insulation resistance (megohms min.): 5000
- Waterproof: None waterproof
- Alternative insert position (deg): 0
