Колектор FESTO FR-8-1/8 61958
Арт.№: 61958
1 от 1
Безплатна доставка над
с куриер Спиди
76.69
€
/
149.99
лв.
ППЦ:
€
€
19.9404
€
/
39.00
лв.
Валидност на промоцията
до
В наличност
Доставка и плащане
Резервирай
и вземи от Добави в любими
Твоите любими продукти Сравни
Характеристики Колектор FESTO FR-8-1/8
Manifold Sub-Base, 8 Outlet, FR Series, G1/8, Festo Pneumatic Valves
- Pneumatic connection, port 1: Female thread G3/8
- Pneumatic connection, port 2: Female thread G1/8
- Number of supply lines: 1
- Number of outputs: 8
Информация
Technical Data
- Nominal size: 8.6 mm
- Mounting position: optional
- Operating pressure complete temperature range: 0 bar ... 16 bar
- Operating medium: Compressed air to ISO 8573-1:2010 [7:-:-]
- Note on operating and pilot medium: Lubricated operation possible (in which case lubricated operation will always be required)
- Corrosion resistance class CRC: 0 - No corrosion stress
- LABS (PWIS) conformity: VDMA24364-B1/B2-L
- Ambient temperature: -10 °C ... 60 °C
- Nominal torque: 12.5 Nm
- Tolerance for nominal tightening torque: ± 20%
- Product weight: 135 g
- Number of outputs: 8
- Number of supply lines: 1
- Pneumatic connection, port 1: Female thread G3/8
- Pneumatic connection, port 2: Female thread G1/8
- Note on materials: RoHS-compliant
- Material housing: Die-cast aluminium
