Kikusui Rental PCR500LE AC Power Supply / Frequency Converter

Kikusui PCR500LE (Three units required for 3 phase) is an extremely high quality programmable variable frequency AC power supply, Measurements include full line voltage simulation, apparent power, power factor, true power, Vrms, Irms , I peak, power W, frequency Hz, harmonic current measurement, Optional plug-in cards extend functionality. USB memory devices can store the data contained on the main unit memory, panel settings, power line abnormality simulations, and sequence data. Usable for systems to test conformance to the IEC61000-3 and 4 Series standards. Optional applications software also offered.

Features:

• High-quality/high-stability output using high-speed linear amplifier
• Capable of various power line abnormality simulations and sequenced programmed operation
• Single phase 500 VA, expandable with optional drivers for single-phase three-wire, and three-phase operation
• Features a full range of measuring functions and supports AC, DC, and AC + DC Outputs
• Variable output impedance
• Power Line Disturbance Immunity Testing Software
• Sequence Creation Software – program sequences of outputs required
• Avionics test software – supports standards MIL-STD-704, RTCA/D0-160 and JIS W0812
• Line Impedance Network option
• IEC DIP simulator (fast voltage dips 1uS to 5uS)
• Measurement of harmonic current
• Soft-start capability for sensitive loads/testing
• Optional plug-in boards: GPIB, USB, Ethernet, external signal input (PCR unit acts as an amplifier), remote control of output (using DC control input), 3 phase boards for interconnection between PCR-LE units
• Detachable front panel
• Eco-friendly function equipped
• RS232 fitted as standard
• Dimensions (mm): 430W x 195H x 600D 17Kg
