IFM PL2654 PL-010-REA01-E-ZVG/US/ /P
Арт.№: 71534
1 от 1
Безплатна доставка над
150.00
лв.
/
76.69
€
ППЦ:
лв.
лв.
1290.00
лв.
/
659.57
€
Валидност на промоцията
до
В наличност
Доставка и плащане
Резервирай
и вземи от Добави в любими
Твоите любими продукти Сравни
Характеристики IFM PL2654 PL-010-REA01-E-ZVG/US/ /P Flush pressure transmitter
Electronic pressure sensor, 3-wire DC, 2-wire DC, no dead space, Zero and span adjustable, Programmable via EPS interface, Sealing cone G1 male, Connector, Analogue output
Информация
IFM PL2654 PL-010-REA01-E-ZVG/US/ /P Flush pressure transmitter
- Characteristics deviation : < ± 0.6
- Pressure rating: 50 bar, 725 psi, 5000 kPa
- Ambient temperature: -25...80 °C
- Output function: 4...20 mA analogue
- Protection: IP 67
- Bursting pressure min.: 150 bar, 2175 psi, 15000 kPa
- Connection: M12 connector
- Operating voltage: 14...30 V DC
- Shortcode: PL-010-REA01-E-ZVG/US/ /P
- Process connection: Sealing cone G1 male
- Application: Type of pressure: relative pressure , Hygienic systems, viscous media and liquids with suspended particles, Liquids and gases
- Medium temperature: -25...80 °C
- Housing materials: stainless steel 316L / 1.4404, PEI, FPM (Viton)
- Product Name: PL2654
- Electrical design: 3-wire DC, 2-wire DC
- SKU ANL5TK7UUI673P
- Materials (wetted parts): ceramics (99.9 % Al2 O3), PTFE, stainless steel 316L / 1.4435, surface characteristics: Ra < 0.4 / Rz 4
- Measuring range: -0.5...10 bar, -7...145 psi, -50...1000 kPa
