Full description

Product Type Features:

• Series = Cradle S/V23054/V23062
• Terminal Type = Plug-in, Solder

Electrical Characteristics:

• Contact - Current Class = 2A to 5A Class
• Contact - Rated Current (A) = 5
• Contact - Limiting Continuous Current (A) = 5
• Contact - Limiting Making Current (A) = 5
• Contact - Limiting Breaking Current (A) = 5
• Insulation - Initial Dielectric Between Coil/Contact Class = 500V to 1000V Class
• Insulation - Initial Dielectric Between Open Contacts (V rms) = 500
• Insulation - Initial Dielectric Between Contacts and Coil (V rms) = 1000
• Contact - Rated Voltage (VAC) = 250
• Contact - Rated Voltage (VDC) = 260
• Contact - Switching Voltage Max. (VAC) = 250
• Contact - Switching Voltage Max. (VDC) = 260
• Contact - Limiting Short-Time Current (A) = 5
• Coil - Rated Voltage (VDC) = 20
• Coil - Resistance (Ω) = 390
• Coil - Rated Power, DC (mW) = 1026
• Coil - Rated Power Class = 1W to 1.5W Class
• Insulation - Initial Dielectric Between Adjacent Contacts (V rms) = 100
• Insulation - Initial Insulation Resistance (MΩ) = 1000

Dimensions:

• Mechanical - Length Class = 30mm to 35mm Class
• Length (mm [in]) = 35.00 [1.378]
• Mechanical - Width Class = 16mm to 20mm Class
• Width (mm [in]) = 19.00 [0.748]
• Mechanical - Height Class = 25mm to 30mm Class
• Height (mm [in]) = 30.00 [1.181]

Body Features:

• Weight (g [oz]) = 27.00 [0.952]
• Mount Type = Socket

Contact Features:

• Contact Material = Ag, gold flashed
• Contact - Number of Poles = 4

Configuration Features:

• Contact - Arrangement = 4 Form C (CO)
• Coil - Magnetic System = Monostable, DC

Industry Standards:

• RoHS/ELV Compliance = RoHS compliant, ELV compliant
• Lead Free Solder Processes = Wave solder capable to 260°C, Wave solder capable to 240°C, Wave solder capable to 265°C
• RoHS/ELV Compliance History = Converted to comply with RoHS directive

Environmental:

• Environmental - Category of Protection = RTI
• Environmental - Ambient Temperature, Max. (°C [°F]) = 70 [158]
• Environmental - Ambient Temperature Class = 50°C to 70°C Class

Packaging Features:

• Packaging Method = Box

Other:

• Brand = Axicom
